Vehicle Coverage:
The KONNWEI KW340 OBDII/EOBD Scanner is specially designed to work with all OBD II compliant vehicles, including those equipped with the next-generation protocol ——Control Area Network (CAN). It is required by EPA that all 1996 and newer vehicles (cars and light trucks) sold in the United States must be OBD II compliant and this includes all Domestic, Asian and European vehicles.
A small number of 1994 and 1995 model year gasoline vehicles are OBD II compliant. To verify if a 1994 or 1995 vehicle is OBD II compliant, check the Vehicle Emissions Control Information (VECI) Label which is located under the hood or by the radiator of most vehicles. If the vehicle is OBD II compliant, the label will designate “OBD II Certified”. Additionally, Government regulations mandate that all OBD II compliant vehicles must have a “common” sixteen- pin Data Link Connector (DLC).
For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant.
PRODUCT FEATURES:
1. Automatic (Startup Scan) or manual ECU connection optional
2. Quickly indicate engine fault codes, with green / yellow / red LED
indicators as fault lights.
3. To read or clear engine fault codes
4. Dynamic display of sensor data stream information
5. View freeze frame data and I/M status information.
6. Read vehicle information: vehicle identification number (VIN), calibration
identification number (CIN), calibration verification number (CVN).
7. One-click DTC, I/M, VIN
8. One-click battery waveform voltage test
9. Dual model theme: main and subtopic for day and night mode
10. Multi-language support.
11. With type C port, free update and print data via PC
